Wavetronix Click 201 - Chapter 24 - Click 304 - RS-232 to RS-485 Converter

In this chapter
 Physical Features
 On-device Configuration
 Computer Configuration
24
e Click 304 converts half-duplex RS-232 communication to RS-485 communication and
vice versa. e Click 304 improves serial communications and also extends the capabilities
of a serial network.
Figure 24.1 – The Click 304
Click 304 —
RS-232 to RS-485 Converter 24
