Wavetronix Click 201 - Chapter 8 - Click 104 - 4-channel DIN Rail Contact Closure

In this chapter
 Physical Features
 Installation
 Configuration
 Rotary Switch
 Front Panel Menu
 Click Supervisor
8
e Click 104 is a 4-channel contact closure module for use with sensors that use Z4 pro-
tocol: HD, Advance and Matrix. It mounts on a DIN rail for power and communication.
Figure 8.1 – The Click 104
Click 104 —
4-channel DIN Rail Contact Closure 8
