In this chapter
Physical Features
Installation and Wiring
Operation
Configuration
9
e Click 110 is used to report vehicle data to a MIDAS outstation when used with Wa-
vetronix SmartSensors. is card plugs directly into an outstation and reports four channels
of detection. Because the Click 110 has two independent serial buses, it can be congured
without interfering with data reporting.
Figure 9.1 – The Click 110
Click 110 —
4-channel Contact Closure Eurocard 9
