CHAPTER 9 CLICK 110 83
A1
Pin Description
A1 Channel 1, normally closed
A2 No connection
A3 Channel 1, normally open
A4 No connection
A5 No connection
A6 No connection
A7 Master fault, normally open
A8 Channel 2 fault, normally closed
A9 Channel 2 common
A10 Channel 2 fault common
A11 Master fault common
A12 No connection
A13 No connection
A14 No connection
A15 Channel 3, normally closed
A16 No connection
A17 Channel 3, normally open
A18 No connection
A19 No connection
A20 No connection
A21 No connection
A22 Channel 4 fault, normally closed
A23 Channel 4 common
A24 Channel 4 fault common
A25 No connection
A26 No connection
A27 No connection
A28 No connection
A29 Reset
A30 No connection
A31 No connection
A32 No connection
Description Pin
Channel 1 fault, normally closed B1
Channel 1 common B2
Channel 1 fault common B3
Master fault, normally closed B4
No connection B5
No connection B6
No connection B7
Channel 2, normally closed B8
No connection B9
Channel 2, normally open B10
No connection B11
No connection B12
No connection B13
Chassis ground B14
Channel 3 fault, normally closed B15
Channel 3 common B16
Channel 3 fault common B17
No connection B18
No connection B19
No connection B20
No connection B21
Channel 4, normally closed B22
No connection B23
Channel 4, normally open B24
No connection B25
No connection B26
No connection B27
No connection B28
No connection B29
+DC (12–24 VDC) B30
No connection B31
-DC (common) B32
Figure 9.4 – Click 110 Pinout with Peek Outstation
