82 CHAPTER 9 CLICK 110
Push-buttons
e faceplate of the Click 110 features two push-buttons. e upper push-button, labeled
Mode Switch, is used to cycle through and select menu and conguration options.
e lower push-button, labeled Reset, will reboot the Click 110. e Click 110 can be re-
booted in any of three ways: via the reset switch, from the outstation via the 64 way DIN
41612, or by power cycling the device. A reboot is the only way to clear a latched fault con-
dition. To reboot using the reset switch, simply press and release the push-button.
DIP Switches
Just behind the faceplate of the Click 110, on the circuit board, is a set of DIP switches.
ese switches are used to congure the Click 110 in Hardware mode. All settings, with
the exception of Outstation mode and disabling fault latching, are also congurable via
Soware mode (front panel menu, or Click Supervisor). See the DIP Switches section of
this chapter for more information.
Installation and Wiring
Use the following steps to install and wire Click 110 devices:
1 If you’re using hardware conguration, set all DIP switches before installing Click 110
devices (this will be covered in the DIP Switches section of this chapter).
2 Insert the cards into the rack.
3 Daisy-chain together all the cards you intend to use in your installation, using short
RJ-11 jumper cables.
4 Connect the rst Click 110 card to the SmartSensor via a surge protector, such as the
Click 200, 222, or 223, and a 60" RJ-11 patch cord.
For your information, this guide includes the pinout for the 64-pin backplane connector
on the the back of the Click 110. However, the pins behave dierently depending on which
Outstation mode the device is set to, Peek or Siemens (for more on Outstation mode, see
the DIP Switches section of this chapter); the dierences all relate to the fault outputs and
whether they are normally opened or normally closed.
For this reason, there are two pinout tables on the following pages. e rst is the pinout
when the Click 110 is set to Peek; the second is when its set to Siemens.
Note
The pins that change between the two tables will be highlighted in light gray for ease
of comparison.
