Wavetronix smartsensor advance - Chapter 3 Connecting Power and Surge Protection

In this chapter
 Mounting the Backplate
 Connecting AC Power
 Providing System Surge Protection
 Terminating the SmartSensor 6-conductor Cable
 Contact Closure Connections
2
After installation, each SmartSensor Advance will need to be integrated into the main
trac cabinet for power and surge protection. is chapter contains information on how to
provide power and surge protection to the intersection preassembled backplate located in
the main trac cabinet.
e intersection preassembled backplate is 11 in. (28 cm) wide and 11.5 in. (29.2 cm) high.
Also available to use are the intersection preassembled 19-inch rack for server racks and the
intersection segmented preassembled backplate for easier installation in trac cabinets. All
wiring on the rack and backplates is done using stranded wires with wire ferrules for screw
terminal connections (see Figure 2.1).
Connecting Power and
Surge Protection 2
