Contents
Chapter 1 Introduction 5
SmartSensor Advance Package 6 • Selecting a Detection
Method 6 • Selecting a Mounting Location 8
Part I Installing the SmartSensor Advance
Chapter 2 Installing the SmartSensor Advance 15
Selecting the Mounting Height 15 • Attaching the Mount
Bracket to the Pole 16 • Attaching the Sensor to the Mount
Bracket 16 • Aligning the Sensor to the Roadway 17 • Apply-
ing Silicon Dielectric Compound 19 • Connecting the Smart-
Sensor 6-conductor Cable 20 • Grounding the Sensor 21
Chapter 3 Connecting Power and Surge Protection 23
Mounting the Backplate 24 • Connecting AC Power 24 •
Providing System Surge Protection 28 • Terminating the
6-conductor Cables 30 • Contact Closure Connections 32
Part II Using SmartSensor Manager Advance
Chapter 4 Installing SmartSensor Manager Advance 35
Installing SSMA 35
Chapter 5 Communication 39
Serial Connection 40 • Internet Connection 41 • Virtual
Connection 42 • Multi-drop Network 45 • Address Book 46 •
To Next Page
