INSTALLATION INSTRUCTIONS AND OWNER’S MANUAL
Chain/ Belt Drive
Models: 3018, 3018DLX, 3522, 3522DLX
IMPORTANT NOTICE!
Read the enclosed instructions carefully before installing/operating
this garage door opener. Pay close attention to all warnings and
notes. This manual MUST be attached to the wall in close proximity
to the garage door.
© Copyright 2006 Wayne-Dalton Corp. Part No. 326568 NEW 6/6/2006
FOR RESIDENTIAL SECTIONAL OVERHEAD GARAGE DOORS ONLY!
DO NOT USE ON ONE PIECE DOORS!
IMPORTANT! THE DOOR AND OPENER WILL NOT FUNCTION PROPERLY UNTIL
INFRARED SAFETY SENSORS ARE INSTALLED AND PROPERLY ADJUSTED!
GARAGE DOORS & OPENERS

Table of Contents

Questions and Answers

  • P
    Phillip HornAug 15, 2025
    What to do if my Wayne-Dalton 3522 Garage Door Opener reverses before closing?
    • P
      Pamela KempAug 15, 2025
      If your Wayne-Dalton Garage Door Opener reverses before fully closing and the light flashes, it indicates that the obstruction sensing system has been activated. This could be due to binding in the door's travel, loose or hanging objects activating the infrared safety sensor, or insufficient closing force. Check for any obstructions in the door's path, remove any hanging objects, and adjust the closing force.
  • J
    john46Aug 18, 2025
    Why won't my Wayne-Dalton Garage Door Opener work with the wall button or remote?
    • V
      virginiakimAug 18, 2025
      If your Wayne-Dalton Garage Door Opener isn't working from either the wall button or the remote, the possible causes are: no power to the opener, a short circuit in the wiring to the opener or wall button, or the motor protector has tripped due to excessive use. To troubleshoot, check the cord to the outlet, wall switch, and circuit breaker. Isolate the issue by disconnecting the wires at the opener from the wall station. If the motor protector tripped, allow the motor to cool for 20 minutes and try again.
  • D
    Dylan RogersAug 21, 2025
    What to do if my Wayne-Dalton 3522 Garage Door Opener closes and then reopens?
    • K
      Kenneth BryantAug 21, 2025
      If your Wayne-Dalton Garage Door Opener closes and then returns to the fully open position, and the opener light flashes, the issue might be due to the door arm adjustment, the close travel adjustment being set beyond the normal door position, obstructions on the floor, or insufficient down force. Adjust the door arm and close travel. Check for stones or ice under the door and remove them. Also, adjust the downforce, ensuring obstruction testing is performed whenever the downforce is changed.
  • C
    Christine HayesAug 25, 2025
    Why does my Wayne-Dalton 3522 light flash and the door doesn't open?
    • M
      mmartinezAug 26, 2025
      If your Wayne-Dalton Garage Door Opener light flashes and the door doesn't open, it usually means something is obstructing the door's travel, the opening force is insufficient, or there's a buildup of ice and snow around the door. Disconnect the door from the operator and operate it by hand to find any obstructions, or call a service person. Adjust the opening force and clear any ice or snow from around the door area.
  • G
    Garrett BennettAug 28, 2025
    How to fix a Wayne-Dalton 3522 that works from the wall button but not the remote?
    • T
      Timothy CobbAug 28, 2025
      If your Wayne-Dalton Garage Door Opener works from the wall button but not the remote, the radio control system may be non-operational. Try replacing the battery in the transmitter. If that doesn't work, the transmitter may not be programmed to the opener. If two or more transmitters don’t work, have the motor control board tested.
  • M
    Michael PerezSep 1, 2025
    What should I do if my Wayne-Dalton Garage Door Opener stops before fully closing?
    • T
      Tammy Mclean DVMSep 1, 2025
      If your Wayne-Dalton Garage Door stops and does not close fully, the close limit might not be set properly. To fix this, adjust the close travel with a screwdriver, turning it clockwise to the desired setting. A 1/4 turn equals 1” of travel.
  • M
    melissa40Sep 4, 2025
    How to adjust a Wayne-Dalton Garage Door Opener that doesn't open fully?
    • M
      Michelle JohnsonSep 4, 2025
      If your Wayne-Dalton Garage Door does not open fully and the light does not flash, the open limit is likely not set properly. Adjust the open travel with a screwdriver, turning it counter-clockwise to the desired setting. A 1/4 turn equals 1” of travel.
  • D
    davidmeadowsSep 7, 2025
    Why does my Wayne-Dalton Garage Door Opener move briefly and then reopen?
    • L
      Leah ButlerSep 7, 2025
      If, when activated with the door in the fully open position, your Wayne-Dalton Garage Door Opener travels for a second or less, stops, returns to the fully open position, and the light flashes, the infrared safety sensors may be out of adjustment or defective, or there may be obstructions in the door opening. Check the alignment of the infrared safety sensors according to the instructions and look for any objects blocking the infrared safety sensors.
  • T
    Timothy JacobsSep 12, 2025
    Why does my Wayne-Dalton 3522 Garage Door Opener light flash after the door fully opens?
    • T
      Terri KimSep 12, 2025
      If your Wayne-Dalton Garage Door fully opens and then the light flashes, the open limit is set too high, and the trolley is hitting the stop bolt. To resolve this, adjust the open travel with a screwdriver, turning it clockwise to the desired setting. A 1/4 turn equals 1” of travel.

Summary

Package Contents

Pre-Installation Inspection

Pre-Installation

Identify Your Door

Identify door type for proper opener installation and safety.

Test Your Door

Perform tests to ensure door balance and proper operation before installation.

Pre-Assembly Check

Verify opener limit switch is set to the closed position before initial power-up.

System Features

Important Safety Instructions

Rail Assembly

Mounting Front Rail Assembly

Setting Idler

Rail Assembly Alignment And Chain Or Belt Setting

Attaching Rail to Opener

Positioning and Installing Front Wall Bracket

Attach Unit to Front Wall Bracket

Positioning Motor End of Opener

Mounting Opener End

Mounting Door Bracket

Installing Light

Wired Wall Station And Entrapment Warning Label Installation

Wired Infrared Safety Sensor Installation

Installation of Wiring for Wired Infrared Safety Sensor

Connecting Wired Infrared Safety Sensor to Opener

Connecting Opener To Outlet

Connecting Trolley To Latch Assembly

Alignment of Wired Infrared Safety Sensors

Setting Trolley Close Position

Connecting Door Arm to Door

Setting Door Close Travel

Setting Door Opening Travel

Contact Obstruction Test

Safety Sensor Obstruction Test

Programming Wireless Keyless Entry (If Included)

Installing Wireless Keyless Entry (If Included)

Power Connection (Permanent Wiring Option)

Adjustable Door Bracket Option

Setting Trolley Close Position; Connecting Door Arm

Operating the Wired Wall Station

Customizing the Settings

Opener Controls

Primary Programming for HomeLink to the Classicdrive

Alternate Programming for HomeLink to the Classicdrive

Adjustments

Adjustment # 1 Opening and Closing Force

Adjust opener force for safe closing and stopping during upward travel.

Adjustment # 2 Contact Obstruction Sensing (Closing Direction)

Ensure door reverses upon contact with a 2x4 or object.

Adjustment # 3 Positive Mechanical Door Lock

System locks door in fully closed position for security.

Programming Transmitter(s) to Opener

Maintenance

Monthly Maintenance

Lubricate parts, inspect fasteners, and test door operation monthly.

Twice a Year

Check chain tension and replace transmitter/keyless entry batteries.

Troubleshooting

Parts Breakdown Rail Assembly - All Models

Parts Breakdown Opener Assembly And Accessories - All Models

Classicdrive Accessories

LIFETIME LIMITED WARRANTY

Cut-Out Template to Aid Installation

Patent Information

FCC and IC Statement

Wayne-Dalton 3522 Specifications
