NOTE: THIS NOTES MANUAL MUST BE ACCOMPANIED BY THE DRAWINGS MANUAL, PART NR. 324627.
© Copyright 2005 Wayne-Dalton Corp.
Part Nr. 324628 - ENGLISH NEW 11/10/2005
Notes Manual of Installation, Use, and Maintenance
In Between Jambs With Integrated Operator I-Drive™
Models: Wayne-Dalton Optimal, Wayne-Dalton Confort,
Wayne-Dalton Diffusion, Wayne-Dalton Prestige+/40mm/Pinnacle
Wayne-Dalton Europe
1 Rue Maurice Hollande
51100 Reims, France
www.waynedaltoneurope.com
NOTICE
:
THIS PRODUCT IS TO BE USED ONLY O
N A SINGLE HOUSEHOLD DOMESTIC DOOR
