19
CONTROL BOARD WIRING DIAGRAM
AVAILABLE ACCESSORIES
Light Fixture, Screw-In
Model no: 3940-CESS
Part no: 295522
Keyless Entry RF Transmitter
Model no: KEP2-B433
Part no: 298393
5 Button Wall Station RF Transmitter
Model no: 5BWS-433
Part no: 294394
3-Button Mini RF Transmitter
Model no: 3BTM-433
Part no: 294389
