Network Video Recorder(NVR)
User Manual
Figure 8-8 Stream interface
Step 2 Set the parameters according to Table 8-4.
Table 8-4 Stream parameters
ID of the video output channel.
NOTE
An IP camera has only one video output
channel. Therefore, only the default value
1 is available.
[Setting method]
Select a value from the
drop-down list box.
[Default value]
1
The device supports two streams.
Streams 1 and 2 use the H.264 codec.
The maximum resolution can be set for
streams 1.
Only a low resolution can be set for
stream 2.
[Setting method]
Select a value from the
drop-down list box.
Stream name.
NOTE
The stream name is combined with Chinese
character, number, character and underline.
[Setting method]
Enter a value manually.
The value cannot exceed
32 bytes.
[Default value]
stream1
To Next Page
