NOTE: Lubricate the o-ring with PAG oil
before installing the high-pressure switch.
10. Install the high-pressure switch into the
receiver/dryer. Install the receiver/dryer on the
right side of the vehicle in front of the right-
rear tire.
NOTE: The location is not critical. Be sure
there is no interference between the cool-
ant pump and any other components.
11. Drill a 1/4 in (7 mm) hole in the transmission
support cross-member on the left side.
12. Install a short length of 3/4 in. hose and a 3/
4 in. to 5/8 in reducer on the output side of
the coolant pump. Torque all hose clamps to
40 in. lbs. +/- 5% (4.5 Nm +/- 5%).
