31
Mercedes Sprinter Kiev
57. Connect the blower motor (1) and thermostat
(2) electrical connectors.
Drain Hoses and Misc.
58. Using the provided “T” fitting, connect both
drain hoses at the right side of the Kiev unit.
NOTE: The drain hose should always run
down-hill from the Kiev unit.
NOTE: Drain hose shown for clarity.
59. Drill a 3/4 in (19 mm) hole in the headliner,
about 6 in (153 mm) from the rear, and 8 in
(203 mm) from the bottom of the headliner.
