19
Mercedes Sprinter Kiev
21. Route the A/C hoses into the engine
compartment. Use the provided heat sleeve as
needed.
22.Using the #12 90 degree service fitting, route
the #12 A/C hose from the A/C compressor
through the hole in the passenger side step-
well, along the roof-line, to the area where
the Kiev unit will be located. Leave enough
hose to connect to the Kiev unit.
23. Using the #8 90 degree service port, route
the #8 A/C hose from the A/C compressor to
the condenser.
