Webasto AT2000STC - Combustion Air Intake Setup

WebastoAirTopInstallationGuide–AT2000STC

6
AirTop2000STCInstallationGuide2020|WebastoThermo&ComfortAustraliaPtyLtd.

2.4 Thecombust i onairinlet(Fig3)(3)hasaslottoaccommodatethewires,ensurethefuelpumpwiressit
neatlyinthisslot.Neverrunthewiresthroughthecombustionairinlettubeasitwillcreateairrestrictions.
 


2.5 Attachingcombustionairtube.Amatchingslotneedstobecutinoneendofthecombustionairtubeto
accommodatethefuelpumpwires.

  


2.6 Usingthe25mmhoseclamp,fixthecombustionairtubetotheinlet(Fig3)(3).
Note:Ensurethatthehoseclamp&fuelpumpwiresarenotrubbing.

Undernocircumstancemaythecombustionairbetakenfromareasoccupiedbypeople.Thecombustionairintake
openingmustnotpointinthedirectionoftravel.Itmustbelocatedsothatitcannotbecomecloggedwithdirtor
roaddebris.
Thecombustionairmustbeextractedusingacombustionairtubesuppliedinthekitandprotectedfromdustand
wateringress.
Fig8
Fig9
–
CombustionAirTube“V”cut.
Fig9a–CombustionAirFilter
