WebastoAirTopInstallationGuide–AT2000STC

7
AirTop2000STCInstallationGuide2020|WebastoThermo&ComfortAustraliaPtyLtd.

2.7 Attachthefuellineusingthe10mmhoseclamp&rubberfuellineconnector,fixtothefuelinlet(Fig3)(5),
thenfixthefuellinetotheopenendoftherubberconnectorandsecurewithanother10mmhoseclamp.
(Ref:Fig8).
2.8 Installthestainless
steelexhaustpipe,usingthe25mmexhaustclamptotheexhaustgasoutlet(Fig3)(5).

Theexhaustpipetemperatureisabove250
o
C.Ensurethattheendcapisproperlymountedandpointingdownwards
(fig11.1).Theexhaustmustnotpointinthedirectionoftravel.Theexhaustmustbesecuredandawayfromheat
sensitivecomponents,vehiclefuellinesandharnesses.Webastocansupplyexhaustlaggingifrequired
.
   








Fig11–Theexhaustorcombustionpipemustbelocatedsothatthey
cannotbecloggedbydirtorroaddebris
Fig10anexhaustmuffleris
suppliedinthekit.
Fig11.1–Ensurethattheendcapisproperlymounted
andpointingdownwardsontheexhaustpipe.
