Thermo Top Z / Thermo Top C
Troubleshooting
53
16 Troubleshooting
16.1. Fault lock-out due to faults in the heater
Fuel is supplied for max. 180 seconds if the flame does not start to burn
.
Fuel is supplied for max. 85 seconds if the flame goes out during
operation.
The fuel supply is shut off immediately if the system overheats
(the temperature limiter is tripped).
In all cases (except a fault in the combustion air fan), the heater
continues to run for 120 seconds after a fault lock-out. The run-on
time may vary depending on the software version in the control
module.
IMPORTANT
A warning is not displayed following a fault lock-out caused by
overheating.
16.2. To reset the heater after a fault lock-out
Reset the heater after a fault lock-out as described in the operating and
maintenance instructions.
