Thermo Top Z / Thermo Top C
Bracket (additional heater only)
35
5 Bracket (additional heater only)
The bracket must be secured to the car body or an intermediate bracket
with at least four M6 screws.
Washers and spring rings must be used.
Washers with a minimum diameter of 22 mm must be used if the body
surfaces are flat.
The bracket must not be secured to the car body with self-tapping
screws.
The holder must be correctly machined in compliance with the minimum
bending radii and in accordance with general technical regulations.
TZea_02_gb_e.fm Seite 35 Montag, 3. Februar 2003 2:09 14
