Weber 600 - Page 4

4
CONNECT FLEXIBLE
HOSE TO REGULATOR
You will need: the 12 foot natural gas supply hose and a
3/4 inch or adjustable wrench.
Thread fitting end of hose onto manifold. Figure 2.
Tighten with wrench.
Figure 2
a)
b)
INSTALL SPLASH
GUARDS
You will need: two splash guards
Position splash guard, flanges to the rear, at the back
of the cooking box assembly. Figure 3 (a). Insert both
wire ends into the mounting holes in the cooking box.
Figure 3.
Note:You will have to bend the splash guards slightly to
fit into the mounting holes.
Position the second splash guard, flanges facing you, at
the front of the cooking box assembly. Insert both wire
ends into the mounting holes in the cooking box.
Figure 3.
Figure 3
(a)
(b)
Flanges at the
back of the
splash guards
Mounting holes
Splash guards
