5
Figure 4
Figure 5
Splash guards open for use. Figure 4.
Splash guards closed for storage. Figure 5.
INSTALL FLAVORIZER
BARS
You will need: seven (Summit 400) or eleven (Summit 600)
flavorizer bars
Set the Flavorizer bars front to back over the burners in
the slots of the Flavorizer Bar/cooking grill support.
Figure 6 (a).
Figure 6
Flavorizer Bar/cooking grill
support
Flavorizer Bar
Slot
