Weber GENESIS E-325s Assembly Guide

25
Replacement Parts
GENESIS E-325s • S-325s
GENESIS SEE-325s
7
11 12 13 15 14 16 17 18 19 20 21 26 28 27 22 31
8
9
1 2 3 5 4 6
29 30
10
23 25 24
GENESIS - E/S-325s LP - US 063021
36 35 34 39 40 41
37 38 32 33 43 45 44 46 47 50 51 49 48 42
8
12 13 14 16 15 17 18 19 20 21 22 27 29 28 23
9
10
1 5 4 7 6
30 31 32
11
24 26 25
2 3
GENESIS - SE-E-325s LP - US 063021
40 43 44 45
41 42 33 34 35 36 37 38 39 47 49 48 50 51 54 55 53 52 46
weber.com

Weber GENESIS E-325s Specifications

General

Main Burners	3
Primary Cooking Area	513 square inches
BTU-per-hour Input	39, 000
Side Burner	No
Sear Zone Burner	Yes
Side Tables	2
Total Cooking Area	669 sq in
Warming Rack Area	156 sq in
Fuel Type	Liquid Propane
Ignition	Electronic
Warranty	10 years
Grill Material	Porcelain-enameled, cast-iron cooking grates
