20
Troubleshooting
Checking the Components of the
Electronic Ignition System
When pressing the ignition button you should hear a
ticking sound. If you cannot hear the ticking sound,
check the battery, then check the wires.
Checking the Battery
There are three potential issues with the battery that
supplies the power to your ignition module that need
to be checked:
1) Some batteries have a plastic protective wrap
around them. (Do not confuse this plastic with
the battery label.) Check that this plastic wrap is
removed.
2) Confirm that the battery is installed correctly (C).
3) If the battery is old, replace it with a new battery.
CALL
CUSTOMER
SERVICE
If you are still experiencing any
problems, contact the CustomerService
Representative in your area using
the contact information on
weber.com.
C
GREASY GRILL (Peeling Paint & Flare-Ups)
SYMPTOM
• Inside of lid appears to have the appearance of peelingpaint.
CAUSE SOLUTION
The flakes you see are accumulated cooking vapors
that have turned into carbon.
This happens over time after repeated use of your
grill. This is not a defect. Clean the lid. Refer to the
“Product Care” section.
SYMPTOM
• Experiencing flare-ups when grilling or preheating.
CAUSE SOLUTION
There is leftover food from the previous meal. Always preheat the grill on the highest setting for 10
to 15 minutes.
The inside of the grill needs to be cleaned thoroughly. Follow the steps in the "Cleaning and Maintenance"
section to clean the grill inside from the top down.
Checking the Wires
There are two potential trouble spots that need to be
checked:
1) Check that the ignition wires are connected
securely to the terminals on the ignition button
under the control panel.
2) Make sure the ignition wires are properly attached
to the ignition module. The wire terminals are color
coded to correspond with the terminals on the
ignition module. The number of wires will vary per
model.
330 Igniter Module Wire Chart
1 2 3 4 5
5
3
1
4
2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Weber GENESIS II E-330 and is the answer not in the manual?

Weber GENESIS II E-330 Specifications

General IconGeneral
Main Burners3
Side BurnerYes
Sear Station BurnerYes
Built-in ThermometerYes
Total Cooking Area669 sq in
BTU-per-hour Input Main Burners39, 000 BTU
Side Burner BTU-per-hour Input12, 000 BTU
Sear Station Burner BTU-per-hour Input9, 000 BTU
Cooking Area513 sq in
Warming Rack Area156 sq in
Grate MaterialPorcelain-enameled cast iron
Lid MaterialStainless steel
iGrill 3 compatibleYes
Side TablesYes
Tool HooksYes
Warranty10 years
