Weber GENESIS II E-330 User Manual

9
Getting Started
LP Tank Installation &
LeakChecking
Installation Location
The tank is hung onto the tank scale which is located
outside the cabinet base under the right side table.
The shape of the collar assembly (the metal protective
ring around the tank valve) determines one of two
directions in which the tank will correctly hang on the
tank scale (A).
Inspect the Tank
1) Confirm that the tank valve is fully closed. Close by
turning valve clockwise.
2) Confirm that the tank valve is the proper mating
type for the regulator (B).
3) Inspect the tank valve, including the internal rubber
seal for damage or debris (C). If damaged, return
tank to local retailer.
Install The Tank
1) Check that all burner control knobs are in the
o position. Check by pushing in and turning
knobs clockwise.
2) Loosen hand nut and rotate tank lock up(D).
3) Lift tank into position on the tank scale (E).
4) Rotate the tank lock down. Tighten the hand nut.
5) Screw the regulator coupling onto the tank valve,
turning clockwise (F). Hand-tighten only. Using a
wrench could damage the regulator coupling and
could cause a leak. Proceed to “CHECKING FOR
GASLEAKS.”
A
B
C
D
E
F

Weber GENESIS II E-330 Specifications

General

Main Burners	3
Side Burner	Yes
Sear Station Burner	Yes
Built-in Thermometer	Yes
Total Cooking Area	669 sq in
BTU-per-hour Input Main Burners	39, 000 BTU
Side Burner BTU-per-hour Input	12, 000 BTU
Sear Station Burner BTU-per-hour Input	9, 000 BTU
Cooking Area	513 sq in
Warming Rack Area	156 sq in
Grate Material	Porcelain-enameled cast iron
Lid Material	Stainless steel
iGrill 3 compatible	Yes
Side Tables	Yes
Tool Hooks	Yes
Warranty	10 years
