WWW.WEBER.COM
®
7
BUILT-IN CUTOUT DETAILED DIMENSIONS - "ISLAND" INSTALLATION
4
5
6
a
c
4
7
b
2
5
4
3
2
3
b
1
1
1
460 660
DIMENSIONS
*1
24" minimum* (610 mm) 24" minimum* (610 mm)
2 16
1
⁄2" (419 mm) 16
1
⁄2" (419 mm)
3 11
1
⁄8" (283 mm) 11
1
⁄8" (283 mm)
4 10
1
⁄2" (267 mm) minimum 10
1
⁄2" (267 mm) minimum
5 24
5
⁄16" (618 mm) 24
5
⁄16" (618 mm)
6 36" (914 mm) maximum 36" (914 mm) maximum
7 34" (864 mm) built-in frame 42" (1067 mm) built-in frame
a
For a countertop treatment: recommended
3
⁄4" (19 mm) overhang
b Gas inlet
c Side burner opening
*Clearance from any surface or structure is at least 24" (610 mm) from the back and sides of the grill or side burner.
BUILT-IN CUTOUT DIMENSIONS
