weBoost Drive Reach User Manual

DRIVE REACH VEHICLE SIGNAL BOOSTER
3
NOTE: When going through car wash,
remember to remove your antenna.
NOTE: The cable is strong enough that it
may be routed under weather stripping
and shut in most vehicle doors without
damaging the cable.
Car/Sedan: Cable routed
into rear side door.
SUV/Van/Hatchback: Cable
routed into top of hatchback door.
Truck: Cable routed into
side door.
______
(STEP 1 cont.)
See options below on how cable can be routed with
different vehicles.

weBoost Drive Reach Specifications

General

Max Gain	50 dB
Impedance	50 Ohms
Connectors	SMA Female
Gain	50 dB
Uplink Frequency Ranges	698-716 MHz, 776-787 MHz, 824-849 MHz, 1710-1755 MHz, 1850-1915 MHz
Downlink Frequency Ranges	728-746 MHz, 746-757 MHz, 869-894 MHz, 1930-1995 MHz, 2110-2155 MHz
Power	12V DC
Dimensions (Amplifier)	6 x 4.5 x 1.5 in
