weBoost Drive Reach User Manual

2
VEHICLE SIGNAL BOOSTER DRIVE REACH
______
Step 1: Mount Outside
Magnetic Antenna
WORKS WITH ALL VEHICLES
Identify a location on the top of your vehicle that is:
 Near the center of the roof
 At least 12 inches away from any other antennas
 At least 12 inches away from any windows
(including sunroofs)
Cle an the surface where you will place the outside
antenna.
Mount the outside antenna by placing on top of vehicle.
NOTE: For aluminum roofs, use the included adhesive disk to secure outside
antenna in place.
12 in. away from windows
(including sunroofs)

weBoost Drive Reach Specifications

General

Max Gain	50 dB
Impedance	50 Ohms
Connectors	SMA Female
Gain	50 dB
Uplink Frequency Ranges	698-716 MHz, 776-787 MHz, 824-849 MHz, 1710-1755 MHz, 1850-1915 MHz
Downlink Frequency Ranges	728-746 MHz, 746-757 MHz, 869-894 MHz, 1930-1995 MHz, 2110-2155 MHz
Power	12V DC
Dimensions (Amplifier)	6 x 4.5 x 1.5 in
