weBoost Drive Reach User Manual

6
VEHICLE SIGNAL BOOSTER DRIVE REACH
______
Step 4: Connect Power
Supply To Booster
Connect the power supply cord to the end of the booster,
labeled “
.”
NOTE: Do NOT connect the power to the Signal Booster until you have
connected both the Inside and Outside Antennas.
Power Supply
from Outside Antenna
from Inside Antenna

weBoost Drive Reach Specifications

General

Max Gain	50 dB
Impedance	50 Ohms
Connectors	SMA Female
Gain	50 dB
Uplink Frequency Ranges	698-716 MHz, 776-787 MHz, 824-849 MHz, 1710-1755 MHz, 1850-1915 MHz
Downlink Frequency Ranges	728-746 MHz, 746-757 MHz, 869-894 MHz, 1930-1995 MHz, 2110-2155 MHz
Power	12V DC
Dimensions (Amplifier)	6 x 4.5 x 1.5 in
