WECON VM AC Drive User Manual V2.0
WECON technology Co., Ltd
- 17 -
Code
Name
Range
Default
Feature
RAM
address
F6.28
User Defined Output
Option(EX)1
0: Running frequency
1: Set frequency
2: Bus Voltage
3: Output Voltage
4: Output Current
5: Output Power
6: Output Torque
7-8: Reserved
9: AI1 Input
10: Reserved
0
○
061C
F6.29
User Defined
Comparison Option 1
Ones Place: Comparison
Option
0: EX == X1(F6.31)
1: EX ≥ X1
2: EX ≤ X1
3: X1 ≤ EX ≤ X2
4: EX & X1=X2
Tens Place: Output Option
0: False Output
1: Truth Output
0
○
061D
F6.30
User Defined Dead
Zone 1
0 to 65535
0
○
061E
F6.31
User Defined Output
Option 1 Comparison 1
0 to 65535
0
○
061F
F6.32
User Defined Output
Option 1 Comparison 2
0 to 65535
0
○
0620
F6.33
User Defined Output
Option(EX)2
Same as F6.28
0
○
0621
F6.34
User Defined
Comparison Option 2
Same as F6.29
0
○
0622
F6.35
User Defined Dead
Zone 2
0 to 65535
0
○
0623
F6.36
User Defined Output
Option 2 Comparison 1
0 to 65535
0
○
0624
F6.37
User Defined Output
Option 2 Comparison 2
0 to 65535
0
○
0625
F7.00
Parameters Copy
Option
0: No Option
1: Download Parameters
from Keypad to VFD
2: Upload Parameters from
VFD to Keypad
0
○
0700
