Code
Name
Range
Default
Feature
RAM
address
1: VFD running
2: Alarm (Error)
3: Frequency level
detection FDT1 output
4: Set frequency reached
5: VFD running at 0Hz
11: Inner PLC cycle
completed
15: VFD ready for running
17: Frequency upper limit
reached
18: Frequency lower limit
reached
19: VFD input voltage too
low
25: Frequency level
detection FDT2 output
40: Running time reached
41: User-defined output 1
42: User-defined output 2
45: VFD running REV
F6.06
Virtual VDO Output
Option
0
●
0606
F6.11
Reserved
0: Set Frequency
1: Running Frequency
2: Output Current
3: Input Voltage
4: Output Voltage
5: RPM
6: Reserved
7: Reserved
8: PID Set Value
9: PID Feedback Value
10: Output Power
11: Bus Voltage
12: Reserved
13: AI Input Value
14: Reserved
15: Reserved
16: IGBT Temperature 1
17: IGBT Temperature 2
0
○
060B
F6.12
AO1 Output Option
0
○
060C
F6.13
Reserved
0
○
060D
F6.15
A01 Output Signal
Offset
-10.0 to 10.0%
0.0%
○
060F
F6.16
AO1 Output Signal
Gain
25.0 to 200.0%
100.0%
●
0610
F6.20
Relay 1 Output Delay
0.0 to 360.0s
0
○
0614
F6.22
Reserved
Reserved
0
○
0616
F6.24
Relay 1 Off Delay
0.0 to 360.0s
0
○
0618
F6.27
Reserved
Reserved
0
○
061B
