WECON VM AC Drive User Manual V2.0
WECON technology Co., Ltd
- 15 -
Code
Name
Range
Default
Feature
RAM
address
F5.37
DI1-DI4 Terminal
Feature Option
0: NO
1: NC
LED Ones Place: DI1
LED Tens Place: DI2
LED Hundreds Place: DI3
LED Thousands Place: DI4
0000
●
0525
F5.41
Analog Input Signal
Option
Ones Place: AI1
Tens Place: Reserved
0: Voltage
1: Current
000
●
0529
F5.42
Analog Input Curve
Option
Ones Place: AI1
Tens Place: Reserved
0: Linear
1: Curve
000
●
052A
F5.60
Terminal Operation
Option
LED Ones Place: Recover
Mode after Free Stop
0: Restore the original
command after signal off
1: Not restore the original
command after signal off
LED Tens Place: Recover
Mode after Emergent Stop
0: Restore the original
command after signal off
1: Not restore the original
command after signal off
LED Hundreds Place:
Working Mode after Error
Reset
0: Can start to run directly
1: Must stop first and then
run
Thousands Place: Reserved
0110
●
050E
F6.00
Reserved
Reserved
0
○
0600
F6.02
Relay Output Option
0: No option
2
○
0602
