WECON VM AC Drive User Manual V2.0
WECON technology Co., Ltd
- 14 -
Code
Name
Range
Default
Feature
RAM
address
switchover terminal 1
21:
Acceleration/deceleration
prohibited
22: PID pause
23: Inner PLC status reset
32: Immediate DC braking
35: Reverse PID action
direction
36: External stop terminal 1
37: Command source
switchover terminal 1
43: PID parameter
switchover terminal
44: User-defined fault 1
45: User-defined fault 2
47: Emergent Stop
49: Deceleration dc braking
50: Clear the current
running time
F5.15
DI Terminal Filter Time
0.000 to 60.000s
0.010s
○
050F
F5.16
Terminal Control
Running Mode
0: 2-wire mode 1
1: 2-wire mode 2
2: 3-wire mode 1
3: 3-wire mode 2
0
●
0510
F5.17
UP/DW Control
Frequency Increase
and Decrease Rate
0.01 to 50.00Hz/s
0.50Hz/s
○
0511
F5.18
AI1 Input Lower Limit
0.00 to 10.00V
0.00V
○
0512
F5.19
AI1 Input Lower Limit
Relative Frequency
Percentage
0.00 to 100.00%
0.00%
○
0513
F5.20
AI1 Input Upper Limit
0.00 to 10.00V
10.00V
○
0514
F5.21
AI1 Input Upper Limit
Relative Frequency
Percentage
0.00 to 100.00%
100.00%
○
0515
F5.22
AI1 Filter Time
0.00-10.00sec
0．10sec
○
0516
F5.33
DI1 Rising Edge Delay
0.0 to 360.0s
0
○
0521
F5.34
DI2 Falling Edge Delay
0.0 to 360.0s
0
○
0522
F5.35
DI2 Rising Edge Delay
0.0 to 360.0s
0
○
0523
F5.36
DI2 Falling Edge Delay
0.0 to 360.0s
0
○
0524
