WECON VM AC Drive User Manual V2.0
WECON technology Co., Ltd
- 13 -
Code
Name
Range
Default
Feature
RAM
address
F4.09
Customized VF Point 4
Frequency
0.00 to F0.10
12.00Hz
●
0408
F4.10
Customized VF Point 4
Voltage
0.0 to 100.0%
31.0%
●
040A
F4.11
Oscillation Suppression
Gain
0.0 - 10.0
5.0
○
041B
F4.12
Oscillation Suppression
Filter Period
1 - 1000ms
50ms
○
040C
F4.16
Auto Voltage Regular
Function(AVR)
0: Invalid
1: Valid
0
○
0410
F5.00
DI1 Function Option
0: No function
1: Forward running (FWD)
2: Reverse running (REV)
3: Three-wire operation
control
4: Forward point
movement (FJOG)
5: Reverse point movement
(RJOG)
6: Terminal UP
7: Terminal DOWN
8: Free stopping
9: Reset
10: Run pause
11: External faults often
open input
12: Multi-stage speed
instruction terminal 1
13: Multi-stage speed
instruction terminal 2
14: Multi-speed instruction
terminal 3
15: Multi-speed instruction
terminal 4
16: Terminal 1 for
acceleration/deceleration
time
selection
17: Terminal 2 for
acceleration/deceleration
time
selection
18: Frequency source
switchover (terminal and
keypad)
19: UP/DOWN setting clear
20: Command source
1
●
0500
F5.01
DI2 Function Option
2
●
0501
F5.02
DI3 Function Option
9
●
0502
F5.03
DI4 Function Option
12
●
0503
F5.10
VDI Function Option
0
●
050A
