WECON VM AC Drive User Manual V2.0
WECON technology Co., Ltd
- 12 -
Code
Name
Range
Default
Feature
RAM
address
Mutual Inductance
VFD Model
F2.10
Motor No-load Current
0.1 to 650.0A
Due to
VFD Model
●
020A
F2.11
Motor Auto Tuning
Option
0: No Option
1:
Full-Tuning(Recommended
when motor can be fully
removed off its load)
2: Quiet-Tuning
(Recommended when
motor can’t be fully
removed off its load)
0
●
020B
F2.12
G/P Model
0: G Model
(for constant torque load)
1: P Model
(for quadratic torque load)
0
◎
020C
F2.13
Turn Ratio of Main and
Auxiliary Coils of
Single-Phase
Asynchronous Motor
10 - 200%
80%
●
020D
F2.14
Single-Phase Motor
Current Calibration
Factor
50 - 200%
120%
●
020E
F4.00
Linear VF Curve
Selection
0: Linear Curve ；
1-9: 1.1-1.9 power VF curve
respectively；
10: Squared VF Curve；
11: Customized VF curve；
0
●
0400
F4.01
Manual Torque Boost
0.1 to 30.0%,0 = Auto
Boost
Due to
VFD Model
○
0401
F4.02
Torque Boost Cut-Off
Frequency
0.0 to 100.0%
100.0%
●
0402
F4.03
Customized VF Point 1
Frequency
0.00 to F0.10
3.00Hz
●
0403
F4.04
Customized VF Point 1
Voltage
0.0 to 100.0%
10.0%
●
0404
F4.05
Customized VF Point 2
Frequency
0.00 to F0.10
5.00Hz
●
0405
F4.06
Customized VF Point 2
Voltage
0.0 to 100.0%
15.0%
●
0406
F4.07
Customized VF Point 3
Frequency
0.00 to F0.10
8.00Hz
●
0407
F4.08
Customized VF Point 3
Voltage
0.0 to 100.0%
22.0%
●
0408
