WECON VM AC Drive User Manual V2.0
WECON technology Co., Ltd
- 11 -
Code
Name
Range
Default
Feature
RAM
address
F1.10
Stopping Option
0: Deceleration Stopping
1: Free Stopping(Or Coast
to stop,means VFD cuts off
its output power
immediately when being
stopped,leaving the motor
and its load to stop totally
due to their inertia)
0
○
010A
F1.11
DC Braking Beginning
Frequency
0.00 to 50.00Hz
1.00Hz
○
010B
F1.12
DC Braking Delay
0.0 to 60.0s
0.0s
○
010D
F1.13
DC Braking Current
0.0 to 150.0%
60.0%
○
010C
F1.14
DC Braking Period
0.0 to 60.0s
0.0s
○
010E
F1.15
Stopping Frequency
0.00 to 60.00Hz
0.50Hz
○
010F
F1.16
Zero Speed Holding
Torque Valid Period
0.0 to 6000.0sec
When it is set to 6000.0s, it
will be kept valid all the
time
0
●
0110
F1.17
Zero Speed Holding
Torque
0.0 to 150.0%
Due to
VFD Model
●
0111
F2.00
Type of Motor
0: 3 Phase Asynchronous
Motor (AM)
1: Permanent Magnet
Synchronous Motor
(PMSM)
2: Single Phase
Asynchronous Motor(Can
only be used with V/F
mode)
0
●
0200
F2.01
Motor Rated Power
0.4 to 1000.0kW
Due to
VFD Model
●
0201
F2.02
Motor Rated Voltage
0 to 440V
Due to
VFD Model
●
0202
F2.03
Motor Rated Current
0.1 to 2000.0A
Due to
VFD Model
0203
F2.04
Motor Rated
Frequency
0.01 to F0.10
Due to
VFD Model
●
0204
F2.05
Motor Rated RPM
0 to 65000rpm
Due to
VFD Model
●
0205
F2.06
Motor Stator
Resistance
0.001 to 65.000
Due to
VFD Model
●
0206
F2.07
Motor Rotor
Resistance
0.001 to 65.000
Due to
VFD Model
●
0207
F2.08
Motor Stator and Rotor
Leakage Inductance
0.1 to 6500.0mH
Due to
VFD Model
●
0208
F2.09
Motor Stator and Rotor
0.1 to 6500.0mH
Due to
●
0209
