WECON VM AC Drive User Manual V2.0
WECON technology Co., Ltd
- 21 -
Code
Name
Range
Default
Feature
RAM
address
F9.03
PID Control Option
LED Ones Place: PID
Control Feature
0: Positive
1: Negative
LED Tens Place: PID Control
Option
0: REV Forbidden
1: REV Permit
LED Hundreds Place:
Reserved LED Thousands
Place: Reserved
0100
○
0903
F9.04
Feedback Signal
Maximum Range
0 to 100.0
100.0
○
0904
F9.05
Proportional Gain (P)
0.00 to 100.00
1.00
○
0905
F9.06
Integration Time (I)
0.00 to 10.00s
0.10s
○
0906
F9.07
Differential Gain (D)
0.00 to 10.00s
0.00s
○
0907
F9.08
REV Cutoff Frequency
0.0 to F0.10
0.00Hz
○
0908
F9.09
PID Control Deviation
Limit
0.0 to 100.0%
0.0%
○
0909
F9.10
Differential Clipping
0.00 to 100.00%
0.10%
○
090A
F9.11
Reserved
Reserved
0.10s
○
090B
F9.12
PID Feedback Filter
Time
0.00 to 100.00s
0.00s
○
090C
F9.13
PID Output Filter Time
0.00 to 60.00s
0.00s
○
090D
F9.14
Proportional Gain (P2)
0.00 to 100.00
1.00
○
090E
F9.15
Integration Time (I2)
0.00 to 10.00s
0.10s
○
090F
F9.16
Differential Gain (D2)
0.00 to 10.00s
0.00s
○
0910
F9.17
PID Switching
Condition
0: Switching Forbidden
1: Switching with DI Input
Signal
2: Automatic switching
based on deviation
0
○
0911
F9.18
Switching Deviation 1
0.0 to F9.19
20.0%
○
0912
F9.19
Switching Deviation 2
F9.18 to 100.0%
80.0%
○
0913
F9.20
PID Preset Output
0.0 to 100.0%
100.0%
○
0914
F9.21
PID Preset Output
Period
0.0 to 6500.0s
0.0s
○
0915
F9.22
Positive Maximum
Value of Twice Output
Deviation
0.00 to 100.00%
1.00%
○
0916
F9.23
Negative Maximum
Value of Twice Output
Deviation
0.00 to 100.00%
1.00%
○
0917
