WECON VM AC Drive User Manual V2.0
WECON technology Co., Ltd
- 22 -
Code
Name
Range
Default
Feature
RAM
address
F9.24
Integral Property
Ones Place: Integral
separation
0: Invalid
1: Valid
Tens Place: When the
output reaches the limit
value, whether to stop the
integration
0: Keep on integration
1: Stop integration
0
○
0918
F9.25
Feedback Offline Alarm
Point
0.0 to 100.0%
0.0%
○
0919
F9.26
Feedback Offline Alarm
Delay
0.0 to 120.0s
1.0s
○
091A
F9.27
Feedback Offline Alarm
Option
0: Keep on PID running
without alarming
1: Stop and alarm
2: Keep on PID running
with alarming
3: Keep on running at
present running frequency
with alarming
0
○
091B
F9.28
PID Option
0: Normal PID
1: Sleepable PID
0
○
091C
F9.29
Sleep Threshold
0.0% to 100.0%
60.0%
○
091D
F9.30
Sleep Delay
0.0 to 3600.0s
3.0s
○
091E
F9.31
Wakeup Threshold
0.0% to 100.0%
20.0%
○
091F
F9.32
Wakeup Delay
0.0 to 3600.0s
3.0s
○
0920
F9.33
Minimum Output
0: F0.14
1: 0Hz
0
●
0921
FA.00
Motor Overload
Protection Option
0: Invalid
1: Valid
1
○
0A00
FA.01
Motor Overload
Protection Level
0.0 to 250.0%
100.0%
○
0A01
FA.02
Reserved
Reserved
Reserved
○
0A02
FA.03
Frequency Limit
0.00Hz - 99.99Hz
0.00Hz
○
0A03
FA.04
Overvoltage Stall
Protection Gain
0 - 500%
100%
○
0A04
FA.05
Overvoltage Stall
Protection Point
110% - 150% * Motor
Rated Voltage
135%
○
0A05
FA.06
Overvoltage Stall
Protection Filter Time
1 - 1000ms
5ms
○
0A06
FA.07
Overcurrent Stall
Protection Gain
0 - 500%
20%
○
0A07
FA.08
Overcurrent Stall
Protection Point
100% - 200% * VFD Rated
Current
150%
○
0A08
