WECON VM AC Drive User Manual V2.0
WECON technology Co., Ltd
- 23 -
Code
Name
Range
Default
Feature
RAM
address
FA.09
Overcurrent Stall
Protection Filter Time
1 - 1000ms
20ms
○
0A09
FA.10
Short-circuit to Ground
Protection Option
0: Invalid
1: Valid
0
○
0A0A
FA.11
AC Input Phase Loss
Protection Option
0: Invalid
1: Valid
1
○
0A0B
FA.12
AC Output Phase Loss
Protection Option
0: Invalid
1: Valid
1
○
0A0C
FA.13
Phase Loss Software
Detection Point
0.0 to 999.9%
15.0%
○
0A0D
FA.14
Reserved
Reserved
0110
●
0A0E
FA.15
Hardware Current &
Voltage Protection
Option
Ones Place: Hardware
Overcurrent Protection
0: Invalid, 1: Valid
Tens Place: Hardware
Overvoltage Protection
0: Invalid, 1: Valid
Hundreds Place: Reserved
Thousands Place: Reserved
1110
○
0A0F
FA.16
Hardware Overcurrent
Protection Point
100 to 220% * VFD Rated
Current
180%
○
0A10
FA.17
Hardware Overcurrent
Protection Delay
1 to 5000ms
500ms
○
0A11
FA.18
Protection Point of Too
Low Bus Voltage
40.0% to 100.0%
100%
○
0A12
FA.19
Protection Point of
Overvoltage
120.0 - 200.0%
100%
○
0A13
FA.20
Auto Error Reset Times
0 to 5
0
○
0A14
FA.21
Auto Error Reset
Interval
0.1 to 100.0s
1.0s
○
0A15
FA.23
Flux Brake Gain
0 - 500%
170%
○
0A16
FA.26
Output power
Correction Factor
0 - 1000%
100%
○
0A1A
FA.27
Output Power Display
Unit
0 – Percentage (%)
1 - kW
0
○
0A1B
FA.28
Speed Tracking Current
Gain
0 to 100.00%
10%
○
0A1C
FA.29
Speed tracking gain
0 to 100.00%
5%
○
0A1D
FA.30
Speed tracking current
10 - 200%
60%
○
0A1E
FA.31
Software Current
Protection Option
0: Invalid, 1: Valid
1
○
0A1F
FA.32
Software Current
Protection Point
200%-300% * VFD Rated
Current
270%
○
0A20
FC.00
RS485(Modbus)Comm
unication Address
1 to 247
1
○
0C00
