5.9.3 Gas Table
Indications for the installation of the appropriate
injector and the adjustment of the air suction cap
Gas type
Connection
power
Injector inlet
minimum pressure
Burner
injector hole
Aspiration air cap
adjuetment
Minimum
power Q min
Maximum
power Q n
Maximum
consumption
MODEL:
mbar mbar 1/100 mm mm Kw Kw m
3
/h kg/h
1 Group
G20
20 1.7 100 1 0.47 1.67 0.177 -
G25
20 1.7 110 1 0.47 1.67 0.177 -
G25
25 2.4 100 1 0.47 1.55 0.164 -
G30/31
28-30/37 3.5 60 3 0.47 1.40 - 0.110
G30/31
50 3.5 60 3 0.47 1.80 - 0.142
2 Groups
G20
20 1.9 110 1 0.69 2.03 0.215 -
G25
20 2.1 135 1 0.69 2.52 0.267 -
G25
25 2.7 110 1 0.69 1.88 0.199
G30/31
28-30/37 5.5 75 3 0.69 2.20 - 0.174
G30/31
50 6.1 65 3 0.69 2.10 - 0.167
3 Groups
G20
20 2.3 135 1 1.16 3.06 0.323 -
G25
20 2.3 145 1 1.16 2.91 0.308 -
G25
25 3.5 135 1 1.16 2.85 0.302 -
G30/31
28-30/37 6.1 80 3 1.16 2.51 - 0.199
G30/31
50 11.3 75 3 1.16 2.84 - 0.225
4 Groups
G20
20 2.5 145 1 1.30 3.55 0.376 -
G25
20 2.5 160 1 1.30 3.55 0.376 -
G25
25 3.8 145 1 1.30 3.30 0.349 -
G30/31
28-30/37 6.8 85 3 1.30 2.85 - 0.225
G30/31
50 11.3 75 3 1.30 2.85 - 0.225

Wega POLARIS Series Specifications

General

Type	Automatic
Material	Stainless Steel
Boiler Capacity	5L / 10L / 12L
Group Heads	1 / 2 / 3
Power	2300W / 3600W / 4800W
Voltage	110V / 220V / 380V
Dimensions	535x520x510mm / 760x520x510mm / 985x520x510mm
Weight	51Kg / 66Kg / 81Kg
Features	Electronic pre-infusion; Independent regulation of boiler pressure; Display; LED lights
