Wega POLARIS Series User Manual

45 of 68
TECHNICIANS manual
ENGLISH
14.2 MACHINE Power Supply
PR
SA
RE
CO
CT
120V
PR
SA
CO
CT
RE
240V
230V
PR
SA
CO
CT
RE
400V
R (L1)
N (L2)
MA
BL GV
CAB
MA
BL
R
S
T
CAB
MA
BL
MA
NE BL GV
R
S
T
N
MA
NEBL GVGR
CAB
MA
BL
CO
IN
R (L1)
N (L2)
MA
BL GV
CAB
R (L1)
N (L2)
MA
BL GV
CAB
13 9 5
1
3
71115
16 12 8
4
2
610
14
13 9 5
1
3
71115
16 12 8
4
2
610
14
13 9 5
1
3
71115
16 12 8
4
2
610
14
13 9 5
1
3
71115
16 12 8
4
2
610
14
S/L2 R/L1
U/T1V/T2
SWITCH POWER SWITCH
CAB Power cable
CO Power switch
CT
Connector
GR Grey
GV Yellow-green
IN Switch
R Phase
S Phase
T Phase
N Neutral
Earth
BL Blue
MA Brown
NE Black
PR Pressure switch
RE Resistance
SA Resistance safety device

Wega POLARIS Series Specifications

General

Type	Automatic
Material	Stainless Steel
Boiler Capacity	5L / 10L / 12L
Group Heads	1 / 2 / 3
Power	2300W / 3600W / 4800W
Voltage	110V / 220V / 380V
Dimensions	535x520x510mm / 760x520x510mm / 985x520x510mm
Weight	51Kg / 66Kg / 81Kg
Features	Electronic pre-infusion; Independent regulation of boiler pressure; Display; LED lights
