Wega POLARIS Series

44 of 68
TECHNICIANS manual
14. WIRING DIAGRAMS
14.1 Connection to the POWER SUPPLY
BL Blue
CAB
Power cable
GR Grey
GV Yellow-green
MA Brown
NE Black
R Phase
S Phase
T Phase
N Neutral
Earth
R
N
MA
BL GV
N
R
S
N
T
R
R
N
MA
GV
NE BL
S
R
T
S
T
R
CAB
CAB
MA
GV
NE BL
CAB
NE GR BL
CAB
MA
GV
CAB
NE GR BL
MA
GV
CAB
NE GR BL
MA
GV
single phase 120-230-240V
3-CONDUCTOR CABLE
single-phase 230-240V
three-phase 230-240V
4-CONDUCTOR CABLE
single-phase 230-240V three-phase 230-240V three-phase 400V
5-CONDUCTOR CABLE (3-phase+Neutral+Earth)
