● Clean the bottom plane of cylinder body with 755 abluent or
industrial alcohol.
● Mount main bearing shell, top thrust ake, and coat oil.
● Sling/Hang up crankshaft, blow oil passage bore with compressed
air and rub main journal and connecting stick journal with towel, then
gently put it in the engine body. Then mount the bottom thrust ake.
Note:
※
Carefully check whether there’s scratching before hang up, and
remove it if necessary.
※
The oil groove of thrust ake should face outside.
● Coat the plane of engine body (connecting face of crankcase) with
510 sealant, and sealant coated should be continuous line.
2.2.2 Assembling Steps (2)
