Note:
※
Coat combustion chamber
※
Coat small end bore of connecting rod, piston pin and its bore with
lubricating oil.
● The sequence of assembling piston rings is: helical spring oil ring,
taper-face ring, trapezoidal barrel-face ring.
Note:
※
Pay attention to the sequence of assembling piston rings and
upward mark. The small face of taper-face ring faces up, and “TOP” face
of trapezoidal ring faces up.
