M10 x 75mm Bolt (22)
M
M10 x 67mm Bolt (11)
M10 x 80mm Bolt (16)
M10 x 90mm Bolt (85)
M
M10 x 198mm Bolt (59)
M8 x 70mm Bolt (81)
M
M8 x 117mm Bolt (68)
M
M10 x 67mm Carriage Bolt (14)
M10 x 95mm Bolt (71)
M8 x 67mm Carriage Bolt (86)
M6 x 65mm Screw (43)
5
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
i
ng is the key number of the part, from the PART LIST near the end of this manual. Note: Some small parts
may have been preattached. If a part is not in the hardware kit, check to see if it has been preattached.
PART IDENTIFICATION CHART
