8
5. Attach the Left Front Upright (25) to the left
Base Extension (2) with two M10 x 95mm Bolts
(32), two M10 Curved Washers (37), and two
M10 Locknuts (35). Do not tighten the
Locknuts yet.
Attach the Right Front Upright (3) in the
same way.
4. Attach the Top Frame (6) to the Rear Upright (5)
with two M10 x 95mm Bolts (32), two M10
Curved Washers (37), and two M10 Locknuts
(
35). Do not tighten the Locknuts yet.
4
5
6
2
3
25
32
32
3
7
37
35
37
37
35
35
35
5
