14. Route the Arm Cable (54) over a V-pulley (46).
Attach the V-pulley, a Large Cable Trap (50), two
Full Guards (41), and an M10 Washer (57) to the
U
pright (3) with an M10 x 63mm Bolt (75) and an
M10 Locknut (56). Make sure that the Cable
T
rap is oriented to hold the Cable in the
groove of the V-pulley.
16. Route the Arm Cable (54) over a V-pulley (46).
Attach the V-pulley, a Large Cable Trap (50), two
Full Guards (41), and an M10 Washer (57) to the
Upright (3) with an M10 x 63mm Bolt (75) and an
M10 Locknut (56). Make sure that the Cable
Trap is oriented to hold the Cable in the
groove of the V-pulley.
15. Route the Arm Cable (54) under a 90mm Pulley
(48). Attach the Pulley and two Half Guards (43)
to the Double U-bracket (63) with an M10 x
46mm Bolt (81) and an M10 Locknut (56). Make
sure that the Half Guards are on the outside
of the U-bracket as shown.
56
3
5
7
46
5
0
41
75
54
4
1
48
43
43
63
81
56
54
56
3
57
46
50
41
75
54
41
16
15
14
17. Grease an M8 x 22mm Shoulder Bolt (65). Attach
the Arm Cable (54) to the indicated Cable Pivot
(39) with the Shoulder Bolt and an M8 Locknut
(58). Make sure that the cable end can pivot
easily on the Shoulder Bolt.
58
65
54
39
Grease
17
12
