5
M10 Nylon
Locknut (34)
M8 Washer (33)
M8 Nylon
Locknut (26)
M10 x 180mm Bolt (36)
M6 x 15mm
Screw (30)
M8 x 15mm
Screw (25)
M4 x 15mm
Screw (28)
M6 x 55mm Screw (35)
M8 x 70mm Carriage Bolt (29)
M6 x 35mm Screw (31)
M10 Washer (37)
M8 x 40mm Bolt (24)
M6 Washer (32)
PART IDENTIFICATION CHART
See the drawings below to identify small parts used in assembly. The number in parentheses below each draw-
ing is the key number of the part, from the PART LIST on page 14. Note: Some small parts may have been
pre-assembled. If a part is not in the parts bag, check to see if it has been preassembled.
