Weider CrossBow User Manual

M10 Nylon Locknut (76)
M8 Nylon Locknut (65)
M6 Black Nylon Locknut (69)
M8 Washer (59)
M10 Split Washer (103)
38mm Round
Inner Cap (38)
25mm Square Inner Cap (54)
19mm Round Inner Cap (78)
38mm x 64mm Inner Cap (41)
M10 x 108mm Bolt (81)
M4 x 16mm Screw (62)
M4 x 12mm Flat
Head Screw (85)
M10 Nut (47)
M10 x 72mm Bolt (64)
M10 x 65mm Button Head Screw (70)
M6 x 16mm Screw (82)
M8 x 19mm Button
Head Screw (86)
M10 x 25mm Button
Head Screw (87)
M10 x 132mm Bolt (66)
M10 x 69mm Bolt (60)
M10 x 107mm Bolt (97)
50mm Square
Inner Cap (98)
57mm Round Outer Cap (27)
50mm Round
Inner Cap (57)
45mm Round
Inner Cap (56)
M8 x 25mm Button
Head Screw (46)
M10 x 66mm Carriage Bolt (83)
M8 Split Washer (52)
19mm Spacer (17)
22mm Spacer (106)
M10 x 47mm Button Head Bolt (71)
M10 x 102mm Button Head Bolt (24)
M10 x 143mm Carriage Bolt (73)
M10 x 116mm Button Head Bolt (40)
M6 x 45mm Screw (58)
M10 Washer (75)
PART IDENTIFICATION CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST on the reverse side of this page. Note: Some small
parts may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
