M10 Nylon
Locknut (58)
M8 Washer (50)
M8 Nylon
Locknut (49)
M8 x 58mm Bolt (46)
M6 Washer (54)
M10 x 145mm Bolt (53)
M6 x 16mm
Screw (41)
25mm Round Outer Cap (62)
M10 x 58mm Bolt (60)
M8 x 52mm Bolt (59)
M4 x 16mm Self-
tapping Screw
(57)
M10 x 93mm Bolt (66)
M10 x 50mm Carriage Bolt (67)
M6 x 40mm Screw (48)
M10 x 72mm Bolt (64)
M10 x 130mm Bolt (65)
M10 Washer (43)
M10 x 57mm Bolt Set (55)
PART IDENTIFICATION CHART
5
See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST on page 18. Note: Some small parts may have been pre-
assembled. If a part is not in the parts bag, check to see if it has been preassembled.
