PART LISTmModel No. 831.153932 R0403A
Key Key Key
No. Qty. Description No. Qty. Description No. Qty. Description
1 2 50ram Washer 44 20 Weight 87 71 M10 Nylon Locknut
2 1 Short Base 45 2 Top Weight 88 1 Lat Cable
3 1 Butterfly Upright 46 1 Swivel Carriage 89 6 12.5mm Spacer
4 1 Squat Upright 47 1 Butterfly Frame 90 1 M8 Washer
5 1 Swivel Upright 48 2 Weight Tube Bumper 91 37 M10 Washer
6 1 Top Frame 49 4 Weight Bumper 92 11 M10 x 95mm Bolt
7 1 Butterfly Top Frame 50 2 Weight Pin 93 13 M10 x 45mm Bolt
8 1 Seat Frame 51 8 M8 x 20mm Button 94 4 M8 x 85mm Bolt
9 1 Seat Upright Head Screw 95 3 M10 x 165mm Bolt
10 1 Leg Lever 52 2 Short Frame Plate 96 2 M10 x 85mm Bolt
11 1 Curl Pad 53 1 Foot Plate 97 1 M6 Washer
12 1 Curl Post 54 2 Long Pad 98 3 M4 Washer
13 1 M10 x 20mm Bolt 55 2 "V"-pulley 99 1 M6 x 65ram Bolt
14 9 M4 x 20mm Self-tap- 56 4 Plastic Washer 100 10 M10 x 50mm Bolt
ping Screw 57 4 Butterfly Cap 101 2 19mm Spacer
15 1 Butterfly Backrest 58 7 50mm x 75mm Inner 102 4 Long Cable Trap
16 1 Seat Cap 103 3 M8 x 25mm Shoulder
17 1 Swivel Cable 59 9 M10 x 65mm Bolt Bolt
18 2 M10 x 60mm Bolt 60 2 "L"-pin w/Tether 104 2 M10 x 80mm Button
19 2 Knee Pad 61 1 Offset Double Head Bolt
20 4 Short Pad "U"-bracket 105 1 50mm Square Inner
21 5 40mm x 50mm Inner 62 1 Double "U"-bracket Cap
Cap 63 2 Pulley Plate 106 1 Long Base
22 1 Ab Strap 64 1 "U"-bracket 107 1 M10 x 75mm Bolt
23 1 Pad Tube 65 1 Adjustment Handle 108 2 M10 x 70mm
24 1 Base Cap 66 2 Swivel Bushings Carriage Bolt
25 1 Left Butterfly Arm 67 1 38mm Square Inner 109 2 Knee Pad Cap
26 1 Right Butterfly Arm Cap 110 12 M10 x 65mm
27 2 Press Handle 68 7 Cable Trap Carriage Bolt
28 2 Long Handgrip 69 1 Butterfly Cable 111 2 50mm Outer Cap
29 2 25ram Round Inner 70 2 Pivot Bracket w/Hole
Cap 71 1 Long Frame Plate 112 1 Pin w/Tether
30 4 Knee Rest Bumper 72 1 Swivel Low Cable 113 1 Large Cable Trap
31 2 Small Pulley Plate 73 1 Squat Cable 114 12 M6 x 16mm Screw
32 1 Squat Arm 74 1 Swivel High Cable 115 1 Adjustment Knob
33 2 Squat Handle 75 1 Leg Lever Cable 116 1 Eyebolt
34 1 50mm x 70ram Inner 76 1 Swivel Cage 117 1 M10 x 20mm Knob
Cap 77 1 Leg Lever Bumper 118 2 M12 Nut
35 1 Squat Backrest 78 22 90mm Pulley 119 4 115mm Pulley
36 4 135mm Handgrip 79 1 Lat Bar 120 2 25mm Round Outer
37 1 Squat Bracket 80 1 Row Bar Cap
38 1 Squat Slider 81 1 Chain # 1 User's Manual
39 4 Roller 82 1 Handle # 1 Exercise Guide
40 8 Roller Bearing 83 3 Cable Clip # 2 Grease Packet
41 1 Squat Knee Rest 84 2 200mm Handgrip # 1 Allen Wrench
42 4 Weight Guide 85 4 M10 x 70mm Bolt
43 2 Weight Tube 86 8 M8 Nylon Locknut
Note: "#" indicates a non-illustrated part. Specifications are subject to change without notice. If a part is missing,
call toll-free 1-800-999-3756. See the back cover of the user's manual to order replacement parts.
