8
3. Orient the Rear Stabilizer (3) so that the warning
decals (B) are in the locations shown.
Attach the Rear Stabilizer (3) to the Frame (1)
with two M10 x 90mm Carriage Bolts (40) and
two M10 Locknuts (57); do not tighten the
Locknuts yet.
3
1
57
B
3
40
57
4. Orient the Seat (18) so that the wide end (C) is
in the location shown.
Attach the Seat (18) and the Seat Bracket (59) to
the Frame (1) with two M6 x 80mm Screws (46)
and two M6 Washers (53).
4
1
18
C
59
46
53
53
